1. Authelia配置

./data/authelia/config/configuration.yml

---
###############################################################
#                   Authelia configuration                    #
###############################################################

server:
  address: 'tcp://:9091'

log:
  level: 'debug'

# 基于时间的一次性密码配置
totp:
  # 是否关闭
  disable: true
  # 身份验证器应用程序中显示的发行者名称
  issuer: 'authelia.com'

# 访问控制（https://www.authelia.com/configuration/security/access-control/）
# deny - 拒绝; bypass - 无需认证; one_factor - 用户名密码认证; two_factor - 二次认证
access_control:
  # 默认策略
  default_policy: 'deny'
  # 规则
  rules:
    - domain: 'public.example.cn'
      policy: 'bypass'
    - domain: 'traefik.example.cn'
      policy: 'one_factor'
    - domain: 'secure.example.cn'
      policy: 'two_factor'

# 身份验证方式配置
identity_providers:
  # OIDC配置
  oidc:
    # 【需要修改】64位随机字符串，可以使用命令（tr -cd '[:alnum:]' < /dev/urandom | fold -w "64" | head -n 1 | tr -d '\n' ; echo）生成
    hmac_secret: 'nIrX4RIilsAIfxddUeamyizomGvRWL8rocVeJyCMD22jU4PTgdSFdMAnfqTC5lEL'
    jwks:
      - key_id: 'jwt_key'
        algorithm: 'RS256'
        use: 'sig'
        # 【需要修改】JWT加密key，可以使用命令（docker run --rm -u "$(id -u):$(id -g)" -v "$(pwd)":/keys authelia/authelia:4.39.3 authelia crypto pair rsa generate --directory /keys）生成到当前文件夹下，使用命令（cat ./private.pem）打印获取
        key: |
          -----BEGIN PRIVATE KEY-----
          MIIEvwIBADANBgkqhkiG9w0BAQEFAASCBKkwggSlAgEAAoIBAQDa7Bwk5EQJTkde
          9wrGGGFIgLM88Izc3wxAw6wstFlupeKBXifSuqSZm0y2TIdjf0578qyoTEU6bnCu
          GuwlEVTPovjgCLJ9jS1MynJ+vtb7cUe58PKyHygUF3M7WOMJKh36cGczMLdz/UE5
          rO0UcScomw0wsxri8+ggtJe4juzS75WdrKpvOM/6JAj0NZsCEdZLxM04JcrApxFo
          WmxyB+SldJzBkaK98xUKdphspptIvJJ/w3SEefTNagbVRzOHp8kCUkKMkUEFAVMH
          fZ68CJjC01rgIluyDmAMCDvwceHiRfDGlQYAwQtSz3YSexN22CJoCRJV5TdowFLL
          wYORnsGFAgMBAAECggEAIfcwBqlDxQ3YFOvPSBzQOyd8p5/KuxoAFKxHMkho97nV
          Aq1REGjU0OA/bqlA+DbwPlrQXuw2cXJhGSIkMTwXJH/sjRXMW55jwN5IFVIWmLxi
          nH69qNUcqsFYp4SK9QkLzadS26ZbUCuiywgBYIKNyMcFrOCc80lUYn6ia4gBRliM
          FEMwEXpknGJOEp8+AeAJUTnjGLmOCL6a7r6rcOCm+Odz7yqKyY9MnsAjh3vZ2th/
          QzwOdWjim9iNSMbEj/C5BqcQ1GmQW1hbdUPJBcvq8VwLsKiAErJYUIzf+lZjlLxh
          VJUXaemBCYXFOjqxxuTBbB7+3I0E5fcuO9yotSBKoQKBgQD6Az8xZmrxq18wZL5T
          Dwh3X5ce/VxoZ9NeDV1AY4DOJdjCo/moIKzPSYTsFSQbrA5qMxeTPpT7T6tGIHFi
          0+ZkPRgToeVEv4CedJ4SxWrVy7qt+TDa3kl19merFFtnkrrDcaDWdA16UXKN+OsK
          kJgHDkpK51roT0Mt0BzjT0YZKwKBgQDgKkHbnGFaaS6HEHCeVCsg2sal5+MyWh68
          fGI6XmMJxSMU9sI6KJobgWDMLNM7kPBeyhH0knL4+CBpQiCbj5GiN9SuunkbxS7C
          VHQImaOVg4JKsan7aMGdrMKXhrp7pFdCqGFAsfC5As2HnxqCHKt0Jy3ivDBw3MKG
          /v6LRFXYDwKBgQCLxYrrtEVvrI5AAOKCjvH9wtw6wAyMdhcuCqyqlbZqCbCgSIoH
          m5ThIkoErmEMc2lvp/azJBaoVUb8oqChTrQMMDeoqicCA0oFzE6fUe1Db22DW8Ab
          bJCHOWWFuJDNW7O8FmeD3Ue3rZcslg/ZTTMhJrUUITmqjL2S/DlaP3SCFwKBgQDR
          eWuVhyrKS+P4vvoeWlT7HLXpLyp2URTL2ggIt08hQCEqY/TYWDy6W0pTQcgar7SP
          P5FL1NavpV7UPcEu3RigWD/dD9BAjSDG5BiSONBO1VeZ6TAJCbl0WI52/qWhCM+q
          MKLAzAdBPEdH5vvkfloR7tLIQEecEA+QCxVemvsFLQKBgQDoxfWf1n2OKdb49QBi
          963yXiU2y3f82h+Pj4u10T7IeDKIbSKP9VDxG3Hs9DQr6CQChKrJ+t8Sy2PFhkNV
          YnQAOd/OFzCJN1NjfZa3z+BfoIdaGU8hZWLAt+RFXpLtKoPI2gHt+BXhlMESmX8U
          f8pO3iWLcEcFoyg1xltkjLLuWw==
          -----END PRIVATE KEY-----
    lifespans:
      access_token: '1h'
      authorize_code: '1m'
      id_token: '1h'
      refresh_token: '90m'
    claims_policies:
      default:
        id_token: ['rat', 'email', 'preferred_username', 'name', 'ext_role', 'ext_mobile', 'ext_address', 'ext_description', 'ext_department']
        custom_claims:
          ext_role:
            attribute: 'role'
          ext_mobile:
            attribute: 'phone_number'
          ext_address:
            attribute: 'street_address'
          ext_description:
            attribute: 'description'
          ext_department:
            attribute: 'department'
    scopes:
      extend:
        claims: ['ext_role', 'ext_mobile', 'ext_address', 'ext_description', 'ext_department']
    clients:
      - client_id: 'example_client_id'
        client_name: 'example_client_name'
        # 【需要修改】42位及以上随机字符串
        client_secret: 'PeqqizzHMN04CigGEgin8kbK6YgKgrkHilGtbaWC63'
        authorization_policy: 'one_factor'
        token_endpoint_auth_method: 'client_secret_post'
        claims_policy: 'default'
        scopes: ['openid', 'profile', 'email', 'extend']
        redirect_uris: ['http://localhost:8080/test/callback', 'http://localhost:5173/cdzmiot/admin/dev-api/oauth2/authelia/callback']

# 会话配置
session:
  # 【需要修改】21位及以上随机字符串
  secret: Li3KiigbUH4xd3BLNotqB
  cookies:
    - name: 'authelia_session'
      # 【需要修改】对应的域名
      domain: 'example.cn'
      # 【需要修改】对应的认证接口路径
      authelia_url: 'https://auth.example.cn'
      expiration: '1 hour'
      inactivity: '5 minutes'
      default_redirection_url: 'https://public.example.cn'

# 身份认证后端配置
authentication_backend:
  password_reset:
    # 是否关闭密码重置
    disable: true
  ldap:
    address: ldap://go-ldap-admin-openldap:389
    implementation: custom
    timeout: 5s
    base_dn: DC=eryajf,DC=net
    additional_users_dn: OU=people
    users_filter: (&({username_attribute}={input})(objectClass=person))
    additional_groups_dn: ''
    groups_filter: (&(uniqueMember={dn})(objectclass=groupOfUniqueNames))
    user: CN=admin,DC=eryajf,DC=net
    password: '123456'
    attributes:
      nickname: givenName
      username: uid
      phone_number: mobile
      street_address: postalAddress
      group_name: businessCategory
      extra:
        departmentNumber:
          name: role
          multi_valued: false
          value_type: string
        description:
          name: description
          multi_valued: false
          value_type: string
        businessCategory:
          name: department
          multi_valued: false
          value_type: string

# 存储配置
storage:
  # 【需要修改】21位及以上随机字符串
  encryption_key: 'nVeh1F9W8vg5jHF3YXYqb'
  # 【需要修改】MYSQL配置
  mysql:
    address: 'tcp://172.18.0.1:3306'
    database: 'YOUR_MYSQL_DATABASE'
    username: 'YOUR_MYSQL_USERNAME'
    password: 'YOUR_MYSQL_PASSWORD'
    timeout: '5s'

# 登录尝试规则，当前配置：2分钟最大重试3次，封禁5分钟
regulation:
  max_retries: 3
  find_time: '2 minutes'
  ban_time: '5 minutes'

# 通知
notifier:
  filesystem:
    filename: '/config/notification.txt'
...

2. docker-compose部署文件

./docker-compose.yml

networks:
  oidc-network:
    external: true
services:

  # OIDC服务
  authelia:
    image: authelia/authelia:4.39.3
    container_name: authelia
    hostname: authelia
    restart: always
    healthcheck:
      disable: true
    environment:
      TZ: Asia/Shanghai
    ports:
      - 39443:9091
    volumes:
      - ./data/authelia/config:/config
    depends_on:
      - openldap
    networks:
      - oidc-network

  # ldap管理工具
  go-ldap-admin:
    image: registry.cn-hangzhou.aliyuncs.com/eryajf/go-ldap-admin
    container_name: go-ldap-admin
    hostname: go-ldap-admin
    restart: always
    environment:
      WAIT_HOSTS: openldap:389
      DB_DRIVER: mysql
      # 请修改下面的 MySql 配置，需自行创建数据库和用户
      MYSQL_HOST: YOUR_MYSQL_HOST
      MYSQL_PORT: YOUR_MYSQL_PORT
      MYSQL_USERNAME: YOUR_MYSQL_USERNAME
      MYSQL_PASSWORD: YOUR_MYSQL_PASSWORD
      MYSQL_DATABASE: YOUR_MYSQL_DATABASE
    ports:
      - 39888:8888
    volumes:
      - ./data/go-ldap-admin:/app/data
    depends_on:
      - openldap
    links:
      - openldap:go-ldap-admin-openldap
    networks:
      - oidc-network

  # ldap服务
  openldap:
    image: registry.cn-hangzhou.aliyuncs.com/eryajf/openldap:1.4.1
    container_name: go-ldap-admin-openldap
    hostname: go-ldap-admin-openldap
    restart: always
    environment:
      TZ: Asia/Shanghai
      LDAP_ORGANISATION: "eryajf.net"
      LDAP_DOMAIN: "eryajf.net"
      LDAP_ADMIN_PASSWORD: "123456"
    command: [ '--copy-service' ]
    volumes:
      - ./data/openldap/database:/var/lib/ldap
      - ./data/openldap/config:/etc/ldap/slapd.d
    ports:
      - 39389:389
    networks:
      - oidc-network

3. SpringBoot集成

pom.xml

<!-- spring security 安全认证 -->
<dependency>
  <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-security</artifactId>
</dependency>
<!-- spring security 集成 OAuth2 -->
<dependency>
    <groupId>org.springframework.security</groupId>
    <artifactId>spring-security-oauth2-client</artifactId>
</dependency>
<dependency>
    <groupId>org.springframework.security</groupId>
    <artifactId>spring-security-oauth2-jose</artifactId>
</dependency>

application.yaml

spring:
  security:
    oauth2:
      # 与Authelia中的配置保持一致
      client:
        registration:
          sso:
            client-id: example_client_id
            client-secret: PeqqizzHMN04CigGEgin8kbK6YgKgrkHilGtbaWC63
            authorization-grant-type: authorization_code
            redirect-uri: http://localhost:8080/test/callback
            scope: ['openid', 'profile', 'email', 'extend']
        provider:
          sso:
            issuer-uri: https://auth.example.cn
            user-name-attribute: preferred_username

SpringSecurityConfig.java

import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity;
import org.springframework.security.config.annotation.web.configuration.WebSecurityConfigurerAdapter;

import static org.springframework.security.config.Customizer.withDefaults;

@EnableWebSecurity(debug = true)
public class SpringSecurityConfig extends WebSecurityConfigurerAdapter {

    @Override
    protected void configure(HttpSecurity http) throws Exception {
        http.formLogin().disable();
        http.csrf().and().cors().disable();
        http.authorizeRequests()
                .mvcMatchers("/test/callback")
                .permitAll()
                .anyRequest().authenticated();
        // 授权码模式回调
        http.oauth2Login(withDefaults());
    }

}

TestController.java

import cn.hutool.http.HttpUtil;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;

import java.util.HashMap;
import java.util.Map;


@RestController
public class UserController {

    @Value("${spring.security.oauth2.client.registration.sso.client-id}")
    private String clientId;

    @Value("${spring.security.oauth2.client.registration.sso.client-secret}")
    private String clientSecret;

    @Value("${spring.security.oauth2.client.registration.sso.authorization-grant-type}")
    private String grantType;

    @Value("${spring.security.oauth2.client.registration.sso.redirect-uri}")
    private String redirectUri;

    @GetMapping("/test/callback")
    public String getTokenByCode(String code) {
        Map<String, Object> paramMap = new HashMap<>();
        paramMap.put("code", code);
        paramMap.put("client_id", clientId);
        paramMap.put("client_secret", clientSecret);
        paramMap.put("grant_type", grantType);
        paramMap.put("redirect_uri", redirectUri);
        return HttpUtil.post("https://auth.example.cn/api/oidc/token", paramMap);
    }

}
